Measurements, clearances and accesses
1.7.1
Dimensions of the duct connections
Models 100 / 175, side ducts (horizontal)
N
O
T
E
Floor plan without the top panel
S1
Lateral supply
R1
Lateral return
Model
ARC /
ARH
A
B
C
D
L1
H1
L2
H2
100 / 125
135
365
212
192
1380
575
1720
570
150 / 175
135
390
212
192
1830
645
2170
570
1
