Model
Q2
[A]
B F1 [A] F2 [A] F3 [A] F4 [A]
F5 [A]
REG.
F7 [A]
REG.
F9 [A]
REG.
100 100 3 x 35 20 20 20 20 12,5 5,8 5,8
125 125 3 x 50 25 25 25 25 12,5 5,8 5,8
( * )
If the unit has power and the green LED V2 on board A1 is off, check that the sequence of
phases L1, L2, L3 is correct.
A
On-site installation. These compo‐
nents are not supplied by the manufac‐
turer
FC Phase control
B Cross-section B [mm
2
]
Wiring diagrams 4
ARC/ARH 100 – 125 wiring diagrams 4.5
