The roofcurb must be attached to the supporting structure of the building roof. To do so, use the nuts
and bolts supplied or use welding.
To prevent humidity or condensation from filtering into the building, all of the outer perimeter must be
insulated and sealed with an extension of the same material used for the roofing finish.
Model A B C D E F
100 / 0125 3237 2085 1542 784 601 535
150 / 175 4287 2535 1990 784 716 420
2.19 Roofcurb mounting base, adjustable type
For installing on sloping building roofs at gradients of up to 5° (9%) in a lengthways direction to the unit
and up to 7° (12%) in a transverse direction (models 100 / 125) or 10° (18%) (models 150 / 175).
2
Options and accessories
2.19 Roofcurb mounting base, adjustable type
48
