1.8 ARC output
1.8.1 ARC ‑ 100 cooling capacities
Return air Outdoor coil air temperature (TS)
Flow rate
m
3
/h
WB
°C
27 °C 35 °C 46 °C
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
TS inlet temp. in indoor coil TS inlet temp. in indoor coil TS inlet temp. in indoor coil
22 24 27 30 22 24 27 30 22 24 27 30
(Mini‐
mum)
16000
23 122 25,4 — 42 58 74 116 27,8 — 40 56 72 105 30,7 — 36 52 68
19 111 24,6 55 66 82 98 105 26,7 53 63 79 95 94 28,8 49 60 75 91
17 105 24 70 76 93 105 96 26,4 65 74 89 96 86 28,6 59 69 85 86
15 94 23,8 76 86 94 94 90 25,9 74 84 90 90 81 28,3 70 81 81 81
(Nominal)
19000
23 126 25,7 — 44 62 81 119 28,2 — 41 60 79 108 31,2 — 38 56 75
19 114 24,9 59 71 90 108 108 27,1 56 69 87 106 97 29,3 52 65 83 97
17 108 24,4 77 85 103 108 99 26,8 71 81 99 99 89 29 64 77 89 89
15 97 24,1 83 95 97 97 93 26,3 81 93 93 93 83 28,7 77 83 83 83
(Maxi‐
mum)
22000
23 129 26,1 — 49 66 87 123 28,6 — 42 64 85 111 31,6 — 39 60 82
19 117 25,3 62 76 97 117 111 27,5 59 74 99 111 99 29,7 56 70 91 91
17 110 24,8 84 92 110 110 102 27,2 77 88 102 102 91 29,4 69 83 91 91
15 99 24,5 90 99 99 99 95 26,7 88 95 95 95 85 29,2 84 85 85 85
* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
1.8.2 ARC ‑ 125 cooling capacities
Return air Outdoor coil air temperature (TS)
Flow rate
m
3
/h
WB
°C
27 °C 35 °C 46 °C
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
PT
kW
PC
kW
Sensible power kW
TS inlet temp. in indoor coil TS inlet temp. in indoor coil TS inlet temp. in indoor coil
22 24 27 30 22 24 27 30 22 24 27 30
(Mini‐
mum)
18000
23 138 30,8 — 48 66 83 131 33,7 — 45 63 81 118 37,3 — 41 59 76
19 126 29,8 63 74 92 110 118 32,4 60 71 89 107 107 35 55 67 85 102
17 118 29,2 80 87 105 118 109 32,1 73 83 100 109 97 34,7 66 78 96 97
15 107 28,8 85 97 107 107 102 31,4 83 94 102 102 91 34,3 78 90 91 91
(Nominal)
21000
23 143 31,2 — 49 70 90 135 34,1 — 47 67 88 122 37,7 — 43 63 83
19 129 30,2 66 80 100 120 122 32,8 63 77 97 117 110 35,4 59 72 93 110
17 122 29,5 87 94 115 122 112 32,5 79 90 110 112 100 35,1 72 85 100 100
15 110 29,2 93 106 110 110 105 31,8 90 103 105 105 94 34,8 86 94 94 94
(Maxi‐
mum)
25000
23 146 31,6 — 51 75 99 138 34,6 — 48 72 96 125 38,3 — 44 68 92
19 133 30,6 70 86 110 133 125 33,3 67 83 107 125 113 36 63 79 103 103
17 125 30 97 103 125 125 115 33 87 99 115 115 103 35,6 78 94 103 103
15 113 29,6 102 113 113 113 108 32,3 99 108 108 108 96 35,3 94 96 96 96
* Data in accordance with Eurovent Rooftop program certification conditions
PT: Total Power; PC: Power absorbed by the compressor
WB: Wet-bulb temperature; TS: Dry bulb temperature.
Installation manual 1
ARC output 1.8
15
