1.12 LOGIC SECTION LAYOUT
50 Hz Models :
PHOTOGRAPH OF
50HZ MODEL LOGIC SECTION
FIG. 41 – LOGIC SECTION LAYOUT
6
7
5
8
ITEM
1
2
3
4
5
6
7
8
DESCRIPTION
Microprocessor Board
Back of Keypad
Back of Display
I/O Expansion Board
Power Supply Board
Relay Output Board #1
Relay Output Board #2
Flow Switch & Customer Connection Terminals
