York MILLENNIUM YCAS0623 User Manual

80
YORK INTERNATIONAL
ISOLATOR DETAILS
DIMENSIONS: mm (inches)
TYPE L W HD A B C D E
R-3 or RD-3
139.7 85.8 73.2 63.5 12.7 104.8 14.4 6.3
(5.5") (3.375") (2.875") (2.5") (0.5") (4.125") (0.563") (0.25")
R-4 or RD-4
158.7 117.6 69.8 76.2 12.7 127.0 14.4 9.6
(6.25") (4.625") (2.75") (3.0") (0.5") (5.0") (0.563") (0.375")
LD04033
LD04737
LD04804
LD04805
R3 / RD3 SERIES R4 / RD4 SERIES
FIG. 26 – ISOLATOR DETAILS
