YORK INTERNATIONAL
112
FORM 150.62-NM7 (103)
FIG. 13 – MICROBOARD LAYOUT
Service and Trou ble shoot ing
TB2
TB1
TB6
TB5
TB4
CLK ON/OFF
JUMPER
TB3
J9
J7
J5
J6
J8
J4
J10
J2
J1
00770VIP
U17
REAL TIME
CLOCK/
BATTERY
