YORK INTERNATIONAL
32
FORM 150.62-NM7 (103)
PHYSICAL DATA (ENGLISH)
YCAL0043E_ - YCAL0377E_
Installation
TABLE 14 – PHYSICAL DATA (ENGLISH)
Model Number YCAL
0043 0057 0073 0087 0107 0117 0133 0147 0157
General Unit Data
Nominal Tons, R-22 11.0 15.1 18.9 24.1 28.8 33.1 36.5 39.7 43.5
Nominal Tons, R-407C 10.7 14.5 18.4 22.7 26.8 31.0 34.2 37.4 40.9
Number of Refrigerant Circuits 111112222
Refrigerant Charge
R-22, ckt1 / ckt2, lbs 32 38 58 65 69 45/45 54/45 54/54 60/54
R-407C, ckt1 / ckt2, lbs 32 38 58 65 69 45/45 54/54 52/52 60/54
Oil Charge, ckt1 / ckt2, gallons 2.2 2.2 2.2 2.2 3.3 2.2/2.2 2.2/2.2 2.2/2.2 2.2/2.2
Shipping Weight
Aluminum Fin Coils, lbs 2472 2488 2857 2933 3279 4689 4752 4822 4906
Copper Fin Coils, lbs 2622 2638 3007 3083 3429 4989 5052 5122 5206
Operating Weight
Aluminum Fin Coils, lbs 2548 2564 2940 3036 3381 4931 4994 5064 5148
Copper Fin Coils, lbs 2762 2778 3275 3371 3717 5300 5363 5433 5517
Compressors, scroll type
Compressors per circuit 222232222
Compressors per unit 222234444
Nominal Tons per compressor 7.5 10 13 15 13 10 / 10 13 / 10 13 / 13 15 / 13
Condenser
Total Face Area ft2 47.2 47.2 66.1 66.1 66.1 128.0 128.0 128.0 128.0
Number of Rows 222332222
Fins per Inch 13 13 13 13 13 13 13 13 13
Condenser Fans
Number of Fans total 222224444
Fan hp/kw 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4 2 / 1.4
Fan RPM 950 950 950 950 950 950 950 950 950
Number of Blades 333333333
Total Chiller CFM 16257 16257 23500 23500 23500 47360 47360 47360 47360
Evaporator, Direct Expansion
Diameter x Length 8”x6’ 8”x6’ 8”x6.5’ 8”x7’ 8”x7’ 10”x8’ 10”x8’ 10”x8’ 10”x8’
Water Volume, gallons 9.2 9.2 10.0 12.3 12.3 29.1 29.1 29.1 29.1
Maximum Water Side Pressure, PSIG 150 150 150 150 150 150 150 150 150
Maximum Refrigerant Side Pressure, PSIG 350 350 350 350 350 350 350 350 350
Minimum Chiller Water Flow Rate, gpm 25 25 30 35 60 60 60 60 60
Maximum Chiller Water Flow Rate, gpm 60 60 70 170 170 300 300 300 300
Water Connections, inches 333446666
