FIG. 18 - FAN CONTACTORS AND 3T TRANSFORMER

COMPONENT LOCATIONS (CON'T)

LD10584

FAN CONTACTORS

4CR-9CR

3T TRANSFORMER

(24VAC to SCR Gate Driver Board

and VSD Logic Board)
