260
JOHNSON CONTROLS
FORM 201.21-NM1 (1223)
MICRO PANEL
PRINT KEY (CON'T)
A sample of the operating data printout is shown below.
The operating data printout is a snapshot of current
system operating conditions when the printout was se-
lected. The sample shows combined printouts of 2, 3,
and 4 circuit units. The actual printout will only show
data for the appropriate chiller type.
Bold italic text below a line of print is
not on the actual printout. Bold italic
text indicates information that may
not be available on all printouts or is
additional information to help explain
the difference in a 2/3 or 4-circuit
printout.
OPERATING DATA PRINTOUT
YORK INTERNATIONAL CORPORATION
LATITUDE SCREW CHILLER
OPERATING DATA
2:04:14 PM 18 JUN 05
SYS 1
NOT RUNNING
SYS 2
COMPRESSOR RUNNING
OPTIONS
CHILLED LIQUID W A T E R
LOCAL/REMOTE MODE R E M O T E
LEAD/LAG CONTROL A U T O M A T I C
REMOTE TEMP RESET D I S A B L E D
REMOTE CURRENT LIMIT 0 T O 1 0 V
REMOTE SOUND LIMIT 4 TO 20 MA
(if Sound Limiting enabled)
LOW AMBIENT CUTOUT E N A B L E D
PROGRAM VALUES
SUCT PRESS CUTOUT 4 4 P S I G
LOW AMBIENT CUTOUT 2 5 . 0 D E G F
LEAVING LIQUID CUTOUT 3 6 . 0 D E G F
MOTOR CURRENT LIMIT 1 0 0 % F L A
PULLDOWN CURRENT LIMIT 1 0 0 % F L A
PULLDOWN LIMIT TIME 0 MIN
SUCTION SUPERHEAT SETP 1 2 . 0 D E G F
UNIT ID NUMBER 0
SOUND LIMIT SETPOINT 1 0 0 %
(if Sound Limiting enabled)
UNIT DATA
LEAVING LIQUID TEMP 4 9 . 0 D E G F
RETURN LIQUID TEMP 5 8 . 2 D E G F
TEMP RATE XXX.X DEGF/MIN
COOLING RANGE 42.0+/-2.0 DEGF
REMOTE SETPOINT 4 4 . 0 D E G F
AMBIENT AIR TEMP 7 4 . 8 D E G F
LEAD SYSTEM SYS 2
FLOW SWITCH O N
EVAPORATOR PUMP RUN O N
EVAPORATOR HEATER O F F
ACTIVE REMOTE CONTROL N O N E
OPERATING HOURS 1=XXXXX, 2=XXXXX
3=XXXXX
(3 circuit)
3=XXXXX, 4=XXXXX
START COUNTER 1=XXXXX, 2=XXXXX
3=XXXXX
(3 circuit)
3=XXXXX, 4=XXXXX
(4 circuit)
SOFTWARE VERSION C . A C S . X X . 0 0
VSD DATA
ACTUAL FREQUENCY X X X . X H Z
COMMAND FREQUENCY X X X . X H Z
DC BUS VOLTAGE X X X V D C
(2 circuit & 3 circuit)
DC BUS VOLTAGES XXX XXX VDC
(4 circuit)
INTERNAL AMBIENT TEMP X X X . X D E G F
COOLING SYSTEM STATUS X X X
BASEPLATE TEMPS XXX XXX DEGF
PRECHARGE SIGNAL X X X
(2 circuit & 3 circuit)
PRECHARGE SIGNALS X X X X X X
(4 circuit)
MOTOR OVERLOADS 1/2 XXX XXX AMPS
MOTOR OVERLOADS 3/4 XXX XXX AMPS
(3 circuit & 4 circuit)
SOFTWARE VERSION C . VSD.XX.00
SYSTEM 1 DATA
COMPRESSOR STATUS O F F
R U N T I M E 0- 0- 0- 0 D-H-M-S
MOTOR CURRENT 0 AMPS 0 % F L A
SUCTION PRESSURE 1 2 5 P S I G
DISCHARGE PRESSURE 1 3 1 P S I G
OIL PRESSURE 1 3 0 P S I G
SUCTION TEMPERATURE 6 8 . 4 D E G F
DISCHARGE TEMPERATURE 6 8 . 8 D E G F
OIL TEMPERATURE 6 8 . 8 D E G F
SAT SUCTION TEMP 7 1 . 8 D E G F
SUCTION SUPERHEAT 3 . 4 D E G F
SAT DISCHARGE TEMP 7 4 . 5 D E G F
DISCHARGE SUPERHEAT 6 . 3 D E G F
MOTOR TMP XXX.X XXX.X XXX.X D E G F
COMPRESSOR SPEED XXX.X %
ECONOMIZER SOLENOID O F F
FLASH TANK LEVEL XXX.X %
FEED VALVE % OPEN XXX.X %
DRAIN VALVE % OPEN XXX.X %
CONDENSER FANS ON 0
COMPRESSOR HEATER O N
RUN PERMISSIVE O N
VSD RUN RELAY O F F
VSD SOFTWARE RUN SIGNAL O F F
SYSTEM 2 DATA
COMPRESSOR STATUS O N
RUN TIME 0-0-15-26 D-H-M-S
MOTOR CURRENT 104 AMPS 8 7 % F L A
SUCTION PRESSURE 5 7 P S I G
DISCHARGE PRESSURE 2 3 3 P S I G
OIL PRESSURE 2 1 8 P S I G
SUCTION TEMPERATURE 4 2 . 9 D E G F
DISCHARGE TEMPERATURE 1 4 5 . 5 D E G F
OIL TEMPERATURE 1 0 2 . 8 D E G F
SAT SUCTION TEMP 3 1 . 7 D E G F
SUCTION SUPERHEAT 1 1 . 2 D E G F
SAT DISCHARGE TEMP 1 1 2 . 1 D E G F
DISCHARGE SUPERHEAT 3 3 . 4 D E G F
