York YHVP User Manual

11
YHVP
YHVP Serie
Water side pressure drop
Coil pressure drop
100 200 300 400 500 600 700
0
10
20
30
40
50
60
Qw
Dp
Pressure drop for mean water temperature of 10°C; for
different temperatures multiply the pressure drop gure by the
K correction factors in the table.
°C 20 30 40 50 60 70 80
K 0,94 0,90 0,86 0,82 0,78 0,74 0,70
Valves pressure drop
Legend
Qw = water ow (l/h)
Dp = pressure drop (kPa)
Kvs 2,5
Kvs 1,6
40
30
20
10
9
8
7
6
5
4
3
2
1
100 200 300 400 600 800 1000 2000 3000 4000
Dp
Qw
Accessories
mod.
Valve Code
DN (Ø) Kvs Not Fitted
1 - 2 15 1/2" 1,6 9025321
3 - 4 20 3/4" 2,5 9025323
mod.
Valve Code
DN (Ø) Kvs Not Fitted
1 - 2 15 1/2" 1,6 9025311
3 - 4 20 3/4" 2,5 9025313
Height for vertical flow
(m)
Water flow (l/h) depending on the length of
horizontal flow
5m 10 m
1 7,6 7,2
2 5,6 5,2
3 4,0 3,7
4 3,2 2,9
Fitted
on the unit
Not fitted
on the unit
ID PCF-M PCF-S
Code
9025319 9025309
PCF condensate drain pump
FV2S 2 way valve
FV3S 3 way valve
