2424

YHVP-ECM

YHVP-ECM Serie

Versions and Main components

YHVP-ECM MODELS WITH ELECTRIC HEATER

All versions are available without valves, with 2 way valve or with 3 way valve tted in the unit.

There are four sizes available in the following versions:

YHVP-ECM-E without infra-red remote control and without valve

YHVP-ECM-E-2V without infra-red remote control with tted 2 way valve

YHVP-ECM-E-3V without infra-red remote control with tted 3 way valve

-----------------------------------------------------------------------------------------

YHVP-ECM-T-E with infra-red remote control and without valve

YHVP-ECM-T-E-2V with infra-red remote control with tted 2 way valve

YHVP-ECM-T-E-3V with infra-red remote control with tted 3 way valve

-------------------------------------------------------------------------------------

YHVP-ECM-MB-E with MB electronic board and without valve

YHVP-ECM-MB-E-2V with MB electronic board with tted 2 way valve

YHVP-ECM-MB-E-3V with MB electronic board with tted 3 way valve

The heater is hermetically sealed and supplied inside the

battery pipes and therefore can be only factory mounted.

The electric heaters of the YHVP-ECM units are single phase

230V supply.

The electric heater is tted with a overheat protection.

The unit is tted with two safety thermostats:

- one thermostat with manual reset;

- one thermostat with automatic reset.

Main technical characteristics

Model

YHVP-ECM

Nominal installed power 1000 Watt 1000 Watt 1500 Watt 1500 Watt

Nominal power voltage 230V ~ 230V ~ 230V ~ 230V ~

Number and section of connecting wires 3 x 1,5mm

3 x 1,5mm

Current input 4,5 A 4,5 A 7 A 7 A

Recommended fuse (Type gG) for overload protection 6 A6 A8 A8 A

YHVP-ECM operating limits with electric heater

Max. ambient temperature for YHVP-ECM with electric coil in heating mode: 25°C.

ELECTRIC HEATER

SAFETY

THERMOSTAT
