30
YHVP/YHVP-ECM
YHVP/YHVP-ECM Serie
Controls and units
MB version
Description ID Code
Wall control (to be used with MB board only) JTM-B 9066331E
JTM-B wall control
Wall control with display that allows controlling one or more
units in Master/Slave mode. The control is equipped with
internal sensor to detect the room temperature, which can
be defined as a priority compared to the return air sensor on
the fan coil.
The JTM-B control features the following functions:
• Switch the appliance ON and OFF.
• Temperature set.
• Modify the set point (when used as a +/- 3° variation of the set point configured from NET supervisory program or PSM-DI).
• Set the fan speed (low, medium, high or autofan).
• Set the operation mode (fan only, cooling, heating).
• Time setting.
• Weekly ON/OFF program.
• Display and change of the fan coil operation parameters.
Dimensions : 110x72x25 mm
