Wall electronic controls
Electrical diagrams are shown on the installation, use and maintenance manual
ID Code
JWC-3V 9066642
T2T
9060174
TMO-503-SV2
9060172
JWC-TQR
9066631K
JWC-T
9066630K
JWC-3V
9066642
CONTROL
IDENTIFICATION
ON-OFF switch
ON-OFF electric heater
Manual 3 speed switch
Manual/Automatic 3 speed selection
Summer/Winter switch
Remote centralized Summer/Winter switch or by an
automatic change-over fitted on the water pipe
Room thermostat for fan control (ON-OFF)
Room thermostat for 1 valve control
Simultaneous thermostatic control of the valves and fan
Room thermostat for chilled water valve (SUMMER) and
electric heater (WINTER) control
(in winter only the heater is working)
Installation of electronic low temperature CUT-OUT
thermostat (NTC)
Installation of bimetallic low temperature CUT-OUT
thermostat (TMM)
CONTROL CODES
CONTROL
OPERATIONS
Control operations
Dimensions: 75x75x30 mm
• Manual 3 speed switch.
• Without thermostatic control.
• It can not control the valves.
