90 Z4Mplus and Z6Mplus User Guide
Routine Care and Adjustments
Cleaning Procedures
Clean the Rewind Option
The Rewind option is required.
Refer to the illustration on next page and perform the following
procedure if adhesive buildup begins to affect peel
performance.
1. Open the printhead assembly.
2. Close the peel assembly to prevent bending the tear-off/peel-off bar during
cleaning. Using the Preventive Maintenance Kit (Zebra part number 47362) or a
solution of 90% Isopropyl and 10% deionized water and swab, remove excess
adhesive from the tear-off/peel-off bar.
3. Open the peel assembly by pivoting the module toward you.
4. Manually rotate the pinch roller and clean thoroughly with solvent and a swab.
5. Close the peel assembly.
6. Close the printhead assembly.
Caution • Ensure printhead is fully open and engaged in the up position. Failure to
latch in the up position could result in the printhead falling on your hand during the
procedure.
Note • Apply minimum force when cleaning the tear-off/peel-off bar! Excessive
force can cause the tear-off/peel-off bar to bend. This can have a negative effect on
peel performance.
Note • When cleaning the tear-off/peel-off bar or the pinch roller, remove excess
solvent with a pad to ensure the solvent has dried before printing.
