Introduction

Z4Mplus and Z6Mplus Printer Overview

Z4Mplus and Z6Mplus User Guide 5

Printer Side View

The illustration below is a simplified view of your printer. Depending on installed

options, your printer may look slightly different.

Number Description

Printhead Assembly

Transmissive Sensor

Label Supply Guide

Label Supply Hanger

Dancer

Label Guide

Printhead Open Lever
