Printer Basics
Load Roll Media
Z4Mplus and Z6Mplus User Guide 49
Liner Removal
1. Cut the liner between the media alignment spindle and the take-up spindle.
2. Rotate the take-up spindle counterclockwise until the rewind media guide is in the
12 o’clock position.
3. Loosen the thumbscrew and slide the rewind media guide to the end of the take-up
spindle.
4. Slide the core with the liner from the take-up spindle.
Rewind Mode
See the instructions below to load media in Rewind Mode:
Refer to the illustration on the next page.
1. Press the printhead open lever. The printhead assembly springs up.
2. Flip down the media supply guide.
3. Slide the media guide as far from the main frame as possible.
4. Place a roll of media on the media supply hanger as shown.
5. Flip up the media supply guide.
6. Slide in the media supply guide until it just touches, but does not restrict, the edge
of the media.
7. Feed the media under the dancer, through the slot in the transmissive sensor, and
under the ribbon sensor.
8. Pull approximately 36 in. (900 mm) of media through the front of the printer.
9. Remove the labels from the first 18 in. (450 mm) of media.
10.Ensure the media is against the back of the transmissive sensor. Slide in the media
guide until it just touches, but does not restrict, the edge of the media.
11. Feed the media over the peel assembly and through the rewind base assembly.
12.Loosen the thumbscrew and slide out the rewind media guide to the end of the
take-up spindle.
Caution • Ensure printhead is fully open and engaged in the up position. Failure to
latch in the up position could result in the printhead falling on your hand during the
procedure.
To Next Page
