14 Z4Mplus and Z6Mplus User Guide

Printer Setup

Load the Ribbon

If the media is thermal transfer material, you must load a ribbon to print labels. See the

illustration below. If the media is direct thermal material, do not load a ribbon.

Number Description

Strip Plate

Printhead Assembly

Ribbon Take-Up Spindle

Ribbon Supply Spindle

Printhead Open Lever
