Specifications
Printing Specifications
2/26/10 ZM400 User Guide for UPS P1016807-001 Rev. A
Printing Specifications
Printing Specifications
Print resolution 203 dots/in. 8 dots/mm
Dot size (width x length) 0.0049 in. x
0.0049 in.
0.125 mm x
0.125 mm
First dot location measured from inside
media backing edge
0.10 in. ± 0.04 in. (2.5 mm ± 1 mm)
Maximum print width 4.09 in. 104 mm
Minimum print length 1 dot row
Maximum continuous print length 157 in. 3988 mm
Bar code modulus
(X) dimension
Picket fence (non-rotated) orientation
4.9 mil to 49 mil
Ladder (rotated) orientation
4.9 mil to 49 mil
Programmable constant print speeds • 2.4 in. (61 mm) per second
• 3 in. through 10 in. per second in 1-in.
increments (76 mm through 254 mm per
second in 25-mm increments)
Thin film printhead with E
3®
Element Energy Control
