Specifications
Media Specifications
108
P1016807-001 Rev. A ZM400 User Guide for UPS 2/26/10
Media Specifications
Media Specifications
Label length Minimum 0.5 in. 13 mm
Maximum 12 in. 305 mm
Label width Minimum 1 in. 25.4 mm
Maximum 4.25 in. 108 mm
Total thickness
(includes liner, if any)
Minimum 0.0023 in. 0.058 mm
Maximum 0.010 in. 0.25 mm
Core size 3 in. 76 mm
Maximum roll diameter 8 in. 203 mm
Maximum fanfold pack size
(length x width x height)
8.0 in. × 4.5 in. × 6.2 in. 203 mm × 114 mm × 157 mm
Inter-label gap Minimum 0.079 in. 2 mm
Preferred 0.118 in. 3 mm
Maximum 0.157 in. 4 mm
Ticket/tag notch size (width x length) 0.25 in. × 0.12 in. 6 mm ×
3 mm
Hole diameter 0.125 in. 3 mm
Notch or hole position
(Centered from inner
media edge)
Minimum 0.15 in. 3.8 mm
Maximum 2.25 in. 57 mm
Black mark
dimensions
Vertical length 0.098 in. to 0.453 in. 2.5 to 11.5 mm
Horizontal width > 0.37 in. >
9.5 mm
Location Within 0.40 in. (1 mm) of inside media edge
Density, in Optical Density Units (ODU) > 1.0 ODU
Maximum media density 0.5 ODU
