36
ESSENTIAL TECHNICAL PARAMETERS
FORCES
Type of tractor Z 6441 Z 7441 Z 8441
Type of engine 7205 1105 1205
Lifting force at end of lower links of the rear 3-point hitch,
within full stroke, at max. usable pressure
- with one auxiliary cylinder (kN)
- With two auxiliary cylinders (kN)
26.4
34.4
41.5
Lifting force at end of lower links of the front 3-point hitch,
within full stroke, at max. usable pressure (kN) 23
POWER AND CONSUMPTION
Type of tractor Z 6441 Z 7441 Z 8441
Type of engine 7205 1105 1205
Power on output shaft (kW±2%)
- at nominal speed engine and shifted speed 1,000 rpm of the
output shaft
New engine having 100 Mh max. 38.5 45.5 52
Run-in engine (over 100 Mh 40.5 48 54.5
Specific consumption of fuel (g.kW
-1
.h
-1
±2%)
- corresponding to the power above 260.7 251.5 279.1
