SJ-20200714160642-002 | 2020-07-27(R1.0)
This procedure describes how to configure the media codec type.
1.
On the main page of the ZXHN H2640, select VoIP > Media. The Phone-1 page is
displayed, see Figure 6-7.
Figure 6-7 Media Page
2.
Set the parameters. For a description of the parameters, refer to Table 6-6.
Table 6-6 Media Parameter Descriptions
Select a codec, which must be the same as that configured in the SS
system.
You can modify priority through this parameter. A lower number
indicates a higher priority.
3.
Click Apply button to apply the changes.
6.6
Configure the Fax
The ZXHN H2640 supports the T30 protocoland V152 protocol fax feature. By default,
the T38 protocol is used.
1.
On the main page of the ZXHN H2640, select VoIP > Fax. The Fax page is
displayed, see Figure 6-8.
