Zte ZXHN H2640 User Manual

ZXHN H2640 Maintenance Management Guide(TIM)
4-10
SJ-20200714160642-002 | 2020-07-27(R1.0)
Figure 4-8 DSL Modulation Parameters
4. Select the DSL modulation types and click Apply button to apply the changes.
Note
 Click All On to select all DSL modulation types.
 Click All Off to cancel all DSL modulation types.
 When you select the Bitswap check box, the system can adjust the modulation bit
of an interfered channel to the bit of other channels.
4.2.2 Configure the Ethernet Connection
This procedure describes how to configure the Ethernet on the network side, so that
user services can be connected to the external network.
The ZXHN H2640 supports Route-based and Bridge-based WAN connections.
Abstract
