Zte ZXHN H3600 User Manual

ZXHN H3600 Maintenance Management Guide
Figure 5-25 Parental Controls
2. Configure the parental controls parameters.
Table 5-18 lists the parental controls parameters.
Table 5-18 Parental Controls Parameters
Parameter Description
On/Off Click Onto enable the parental controls function.
Name The name of parental control.
User Identity Configure the user information according to the IP address or MAC
address.
If the All user option is selected, all the users that use the ZXHN
H3600 device are included.
Days Specify the days when the parent control settings are applied.
Duration Specify the time when the parent control settings are applied.
Action The device supports:

Ban Internet Access
After this mode is selected, Internet access is not allowed.

URL Black List
After this mode is selected, websites set in URL are filtered out,
and cannot be visited.

URL White List
After this mode is selected, only websites set in URL can be ac-
cessed.
3. Click Apply button to apply the changes.
42 SJ-20201203151144-003 | 2021-06-16(R1.0)

Zte ZXHN H3600 Specifications

General

Category	Gateway
POTS Ports	2
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Model	ZXHN H3600
Wi-Fi Standard	IEEE 802.11b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Antenna Type	Internal
Security	WPA/WPA2, WEP
Device Type	GPON ONT
Antennas	4
GPON Interface	1 x GPON
Ethernet Ports	4 x GE
