Zte ZXHN H3600 User Manual

ZXHN H3600 Maintenance Management Guide
Parameter Description
Periodic Inform Enable the periodic inform function.
Periodic Inform Interval Periodic inform interval of the device (unit: second).
Authenticating ACS Enable the TR-069 authenticating ACS.
ACS CA Certificate Chain

Auto: Automatically select the first chain certifcate authenti-
cation or the second chain certificate authentication

Chain1: The first chain certifcate authentication

Chain2: The second chain certifcate authentication
4. Click Apply button to apply the changes.
Configure the STUN
1. Click STUN Configuration to the STUN configuration page, see Figure 8-10.
Figure 8-10 STUN Configuration
2. Configure the STUN configuration parameters. Table 8-5 lists the STUN configura-
tion parameters.
Table 8-5 Parameter Descriptions for the STUN Configuration
Parameter Description
Enable After the STUN function is enabled, clients after NAT (or mul-
tiple NAT) can find their public network addresses, and deter-
mine the type of NAT and the Internet port bound to the local
port. These information is used to create UDP communication
between two hosts after the NAT router.
Server Address The address of the server
3. Click Apply button to apply the changes.
Configure the Certificate
1. Click Certificate Management to the certificate management page, see Figure 8-11.
86 SJ-20201203151144-003 | 2021-06-16(R1.0)

Zte ZXHN H3600 Specifications

General

Category	Gateway
POTS Ports	2
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Model	ZXHN H3600
Wi-Fi Standard	IEEE 802.11b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Antenna Type	Internal
Security	WPA/WPA2, WEP
Device Type	GPON ONT
Antennas	4
GPON Interface	1 x GPON
Ethernet Ports	4 x GE
