Chapter4ServiceConguration
zxr10(cfg)#setzesrdomain1major-levelmodetransit
zxr10(cfg)#setzesrdomain1enable
Note:
1.ZESRportincontrolVLANmustbeconguredastagport.
2.BeforeenablingZESRfunction,STPfunctionmustbeenabled.
3.Theprimaryportandthesecondaryportinmasternodearedifferentonfunction.
Normally,theprimaryportissetasforwardingstatus,butthesecondaryportis
setasblockingstatus.
4.Theprimaryportandthesecondaryportintransitnodearethesameonfunction.
Normally,theyarebothsetasforwardingstatus.
ZESRMulti-RingNetworkingExample
lCongurationDescription
AsshowninFigure4-42,themultiringnetworkingcomposedof6switchesisshown
above.ThereareoneZESRprimaryringandtwohierarchicalrings.
1.TheprimaryringiscomposedofnodesS1~S4.S1isMaster,P1isthePrimary
Port,P2istheSecondaryPort,S2istheTransitnode,S3~S4areEdge-Transit
node,P3andP4aretheedge-portofthetwohierarchicalrings.
2.Thelink1ofhierarchicalringiscomposedofS6,S3andS4.S6istheMaster,P1
isthePrimaryPort,P2istheSecondaryPort,S3andS4aretheassistingnodes.
3.Thelink2ofhierarchicalring1iscomposedofS5,S3andS4.S5istheMaster,
P1isthePrimaryPort,P2istheSecondaryPort,S3andS4aretheassisting
nodes.
Theprotectinstanceintheringis1,theprotecteddataisVLAN100andtheprotocol
VLANisVLAN4000.
4-103
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2918E Specifications

General

VLANs	4K
Jumbo Frame	9K
Power Supply	AC: 100~240V, 50~60Hz
Operating Temperature	0°C~45°C
Storage Temperature	-40°C~70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5%~95% (non-condensing)
Power Consumption	<=25W
