ABB A43 User Manual

Communication with Modbus
2CMC48001M0201 125 A43/A44
Revision: C User Manual
Averages of instrumentation values
Averages of instrumentation values are used in load profile recording.
The following table lists the OBIS codes for averaging of instrumentation values:
Quantity
OBIS code
Voltage L1
1.0.32.27.0.255
Voltage L2
1.0.52.27.0.255
Voltage L3
1.0.72.27.0.255
Voltage L1-L2
1.0.134.27.0.255
Voltage L2-L3
1.0.135.27.0.255
Voltage L1-L3
1.0.136.27.0.255
Current L1
1.0.31.27.0.255
Current L2
1.0.51.27.0.255
Current L3
1.0.71.27.0.255
Current N
1.0.91.27.0.255
Power factor total
1.0.13.27.0.255
Power factor L1
1.0.33.27.0.255
Power factor L2
1.0.53.27.0.255
Power factor L3
1.0.73.27.0.255
Min/Max of instrumentation values and powers
Minimum and maximum of instrumentation values and powers are used for
the Demand function. In the table below the byte shown as X can have any of
the values 3, 6, 13 or 16. The meaning of these values is described after the
OBIS code table.
The following table lists the OBIS codes for minimum/maximum
of instrumentation values and powers:
Quantity
OBIS code
Voltage L1
1.0.32.X.0.255
Voltage L2
1.0.52.X.0.255
Voltage L3
1.0.72.X.0.255
Voltage L1-L2
1.0.134.X.0.255
Voltage L2-L3
1.0.135.X.0.255
Voltage L1-L3
1.0.136.X.0.255
