ABB AC 31 User Manual

Installation
ABB Control - AC 31 Page 4-25
1SBC 260400 R1001-b 06.99
5.4. Summary
Master central unit
40 and 50 series
addresses address configuration
- Incorporated Inputs/Outputs 62 standard
- Binary extension 63 to 68 automatically
- Analog extension 63 to 68 automatically
Analog channel addressing:
On central units On extensible remote units ( address Y )
Address
63 ≤ X ≤ 68 0 ≤ Y ≤ 61
XM 06 B5 Max 6 extensions Max 2 extensions
First extension Second extension
- inputs IW X.00 to IW X.03 IW Y.00 to IW Y.03 IW Y.04 to IW Y.07
- outputs OW X.00 and OW X.01 OW Y.00 and OW
Y.01
OW Y.04 and OW
Y.05
- internal values OW X.02 and OW X.03 OW Y.02 and OW
Y.03
OW Y.06 and OW
Y.07
XE 08 B5 Max 6 extensions Max only one
- inputs IW X.00 to IW X.07 IW Y.00 to IW Y.07
XTC 08 Max 6 extensions Max only one
- internal values OW X.00 to OW X.07 OW Y.00 to OW Y.07
RU
Addresses Y N
With Y = address of the extensible remote unit,
and N = maximum number of extensions of one type on an extensible remote unit.
Master central unit address configuration
50 series 90 series
- Extensible remote unit by rotative switches
If solely binary extension
0 ≤ Y+N ≤ 61 0 ≤ Y+N ≤ 61
automatically
If at least one analog extension
0 ≤ Y+N ≤61 0 ≤ Y ≤5
automatically
- 50 series slave central unit
Binary configuration 0 to 61 0 to 61 by programming software
Analog configuration 0 to 61 0 to 5 by programming software
- 90 series slave central unit
Binary configuration 0 to 61 0 to 61 by programming software
Analog configuration 0 to 5 0 to 5 by programming software
