Technical specifications
Page 3-22 ABB Control - AC 31
1SBC 260400 R1001-b 06.99
6.3. Technical specifications of the analog extension
The analog extensions are powered at 5 V and 24 V d.c. by the central unit or extensible
remote unit to which they are connected.
The analog value with a customized format of each channel is displayed on a 4 digit display.
The channel number is selected by the push button on the front side.
Warning: the extensions must not be connected or disconnected under power supply.
Warning: In the configuration current 4 – 20 mA, the sensor should be able to provide 20 mA
with min 10 V d.c. Moreover, the input is not protected against voltage between 10 up to 18 V
d.c. and can give an error or destroy the input.
XM 06 B5 XE 08 B5 XTC 08
- Number of analog inputs 4 8 -
- Number of analog outputs 2 - -
- Number of displayed internal values - 8
- Display values - Scale +/- 9999 +/- 9999 +/- 9999
- Filtering of 50 / 60 Hz yes yes
- Transfer time of the analog I/O 120 ms */ 50 ms 220 ms *
- Maximum power dissipation 3 W 3 W
- Weight 200 g 200 g 150 g
Analog inputs Voltage Current Pt 100 Pt 1000
- Nominal range:
- Maximum values
+/- 10 V
+/- 30 V
0…20 mA
4…20 mA
+/- 25 mA
- 200 °C
+ 450 °C
- 200 °C
+ 450 °C
- Isolation of inputs / electronic
- Resolution
500 V
12 bits + sign
500 V
12 bits
500 V 500 V
- Min resolution at input (± 1LSB)
- Full scale precision
+/- 2,5 mV
≤+/- 0,7 %
+/- 5 µA
≤+/- 0,8 %
+/- 0,1 °C
≤+/- 1,5 °C
+/- 0,1 °C
≤+/- 1,5 °C
- Word value range read by the
central unit
+/- 32767 0…32767 - 2000/+4500 - 2000/+4500
- Amplification error between two
channels
70 dB 70 dB 70 dB 70 dB
- Input impedance
100 KΩ 100 Ω 100 KΩ 100 KΩ
- Linearization for
Pt 100 / Pt 1000 probe
yes yes yes yes
- Temperature coefficient 100 ppm 100 ppm 100 ppm 100 ppm
- Dissipation sensor:
0°C
450°C
0,625 mW
1,6 mW
0,0625 mW
0,16 mW
- Acquisition time including filtering
time for all channels
120 ms * 120 ms * 220 ms * 220 ms *
- Diagnosis No No No No
- Cable length:
shielded
short-circuited unused channels
50 m
yes
yes
50 m
yes
yes
50 m
yes
yes
50 m
yes
yes
* without filtering time 50 and 60 hz
