Presentation / operation
Page 1-4 ABB Control - AC 31
1SBC 260400 R1001-b 06.99
07KR51
or
07CT41
XI16E1 XO08R1 XC08L1 XM06B5
Max. 6 binary or analog extensions
Figure 1-1 : A central unit with extensions
07KR51 XI16E1 XO08R1
Max. 31 bus connection points
Max. 500 m without amplifier
Max. 2000 m with amplifiers
ICMK14F1 XC08L1 XM06B5 TCAD ACS600
variable
speed drive
with a
NCSA-01
interface
CS 31 bus = RS485 line
Max. 6 extensions
therefore a max. of 8 analog
inputs and 8 analog outputs
Figure 1-2 : Central unit with extensions and CS 31 bus
