ABB AC 31 User Manual

Diagnosis
Page 8-8 ABB Control - AC 31
1SBC 260400 R1001-b 06.99
Class 1 errors:
fatal errors
Class 2 errors:
serious errors
Class 3 errors:
light errors
Class 4 errors:
warnings
Error signaled by the
error bit:
M 255.10 = 1
Type of error signaled
by:
M 255.11 = 1
M 255.12 = 1 M 255.13 = 1 M 255.14 = 1
Error code in: MW 254.00 MW 254.08 MW 255.00 MW 255.08
Detailed information
in :
Information 1
Information 2
Information 3
Information 4
MW 254.01
MW 254.02
MW 254.03
MW 254.04
MW 254.09
MW 254.10
MW 254.11
MW 254.12
MW 255.01
MW 255.02
MW 255.03
MW 255.04
MW 255.09
MW 255.10
MW 255.11
MW 255.12
Hard version of unit*
Soft version of unit*
Unit serial number*
MW 254.05
MW 254.06
MW 254.07
MW 254.13
MW 254.14
MW 254.15
MW 255.05
MW 255.06
MW 255.07
MW 255.13
MW 255.14
MW 255.15
Acknowledgment
through programming
in the central unit
This acknowledgment
only acknowledges the
errors on the central
unit not those signaled
by a remote unit
By setting M 255.13
to 0 after the
disappearance of the
error
By setting M 255.14
to 0 after the
disappearance of the
error
Acknowledgment
through programming
in the central unit and
remote units
With the CS31QU function block
* Information unavailable on certain AC 31 units
The error bit M 255.10 is 1 if any of the error bits M 255.11 to M 255.14 are at 1. The central
unit has not found an error if M 255.10 = 0.
The error bit M 255.10 is automatically reset to 0 when the error type bits are acknowledged.
A class 4 error (M 255.14=1) when MW 255.08
≤ 15 acknowledges automatically. Class 3 or 4
type errors may be acknowledged by setting M 255.13 or M 255.14 to 0.
The information word values are updated with each new error. Resetting these words to 0 is
not automatic when acknowledged but may be achieved by writing, on-line or through
programming, a 0 value in these words.
