In the CODESYS editor menu select “Project è Build”
ð
The result of the compiling is shown in the “Messages” field at the bottom of the
screen.
If you skip the compiling and select “Login”, the Automation Builder will automatically trigger
compiling in advance to logging-in.
1.6.4.5 Save CODESYS project
In the CODESYS editor menu select “File è Save”.
Alternatively, select the save icon
in the tool bar.
Alternatively, press [Ctrl] + [S].
1.6.4.6 Loading the project to the CPU
Download the project to the CPU
Ä
as described in Chapter 1.5.6 , on page 35.
1.6.5 Test the program
1.6.5.1 Start the program execution
You are logged in the CPU.
An executable project is loaded to the CPU.
The CPU is in "stop" mode.
Getting started with example projects
Example project for remote I/O expansion with PROFINET > Test the program
2023/03/033ADR010649, 3, en_US62
