Functions in the main Menu 37
Assistants
In the Assistants menu, you can launch an assistant. An assistant is a sequence of
steps that help you to complete a task, such as setting up the control panel to use
with the drive and the motor, or fixing a fault.
1. Use and to highlight the desired
assistant.
2. Press (Select).
3. Follow the instructions on the screen to
complete the task defined by the assistant:
• Use and to select settings.
• To edit a setting, press (Edit or
Select).
• Use and to move between the pages of the assistant. The progress bar
on the upper right corner of the screen indicates the progress.
• To exit the assistant, press (Exit).
Most settings accessed in assistant steps can also be accessed through the main
Menu or the Parameters menu, but in the assistants they are presented in a more
user-friendly fashion.
Energy efficiency
In the Energy efficiency menu, you can view and
configure parameters related to energy savings,
such as kWh counters.
Event log
In the Event log menu, you can view information
collected on faults and warnings. Events are
automatically logged. See Fault tracing (page 51)
for more information on faults and warnings.
• Faults sub-menu displays the faults that
are tripped the drive.
• Other events sub-menu displays all other
faults, and warnings and their details.
• Active faults and Active warnings sub-menu displays the faults and
warnings which are active.
