ABB ACS150 User Manual

Technical data
113
Technical data
What this chapter contains
The chapter contains the technical specifications of the drive, e.g. the ratings, sizes
and technical requirements as well as provisions for fulfilling the requirements for CE
and other marks.
Ratings
Current and power
The current and power ratings are given below. The symbols are described below
the table.
1)
E=EMC filter connected, U=EMC filter disconnected. Metal EMC filter screw is installed in “E”
versions and plastic screw in “U” versions.
Type Input Output Frame
size
ACS150- I
1N
I
2N
I
2,1min/10min
I
2max
P
N
x = E/U
1)
AAAAkWHP
1-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
01x-02A4-2 6.1 2.4 3.6 4.2 0.37 0.5 R0
01x-04A7-2 11.4 4.7 7.1 8.2 0.75 1 R1
01x-06A7-2 16.1 6.7 10.1 11.7 1.1 1.5 R1
01x-07A5-2 16.8 7.5 11.3 13.1 1.5 2 R2
01x-09A8-2 21.0 9.8 14.7 17.2 2.2 3 R2
3-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
03x-02A4-2 3.6 2.4 3.6 4.2 0.37 0.5 R0
03x-03A5-2 5.0 3.5 5.3 6.1 0.55 0.75 R0
03x-04A7-2 6.7 4.7 7.1 8.2 0.75 1 R1
03x-06A7-2 9.4 6.7 10.1 11.7 1.1 1.5 R1
03x-07A5-2 9.8 7.5 11.3 13.1 1.5 2 R1
03x-09A8-2 11.8 9.8 14.7 17.2 2.2 3 R2
3-phase U
N
= 380…480 V (380, 400, 415, 440, 460, 480 V)
03x-01A2-4 2.2 1.2 1.8 2.1 0.37 0.5 R0
03x-01A9-4 3.6 1.9 2.9 3.3 0.55 0.75 R0
03x-02A4-4 4.1 2.4 3.6 4.2 0.75 1 R1
03x-03A3-4 6.0 3.3 5.0 5.8 1.1 1.5 R1
03x-04A1-4 6.9 4.1 6.2 7.2 1.5 2 R1
03x-05A6-4 9.6 5.6 8.4 9.8 2.2 3 R1
03x-07A3-4 11.6 7.3 11.0 12.8 3 3 R1
03x-08A8-4 13.6 8.8 13.2 15.4 4 5 R1
00353783.xls E
