ABB ACS150 User Manual

Hardware description
17
Type code
The type code contains information on the specifications and configuration of the
drive. You find the type code on the type designation label attached to the drive. The
first digits from the left express the basic configuration, for example ACS150-03E-
08A8-4. The explanations of the type code selections are described below.
ACS150-03E-08A8-4
ACS150 product series
01 = 1-phase input
03 = 3-phase input
1-phase/3-phase
In format xxAy, where xx indicates the integer part and y the fractional part,
e.g. 08A8 means 8.8 A.
For more information, see section Ratings on page 113 .
Output current rating
2 = 200…240 VAC
4 = 380…480 VAC
Input voltage range
E = EMC filter connected, 50 Hz frequency
U = EMC filter disconnected, 60 Hz frequency
Configuration
