Technical data
119
Input power connection
Voltage (U
1
) 200/208/220/230/240 VAC 1-phase for 200 VAC drives
200/208/220/230/240 VAC 3-phase for 200 VAC drives
380/400/415/440/460/480 VAC 3-phase for 400 VAC drives
Regular 10% variation from converter nominal voltage is allowed as default.
Short-circuit capacity Maximum allowed prospective short-circuit current at the input power connection as
defined in IEC 60439-1 is 100 kA. The drive is suitable for use in a circuit capable of
delivering not more than 100 kA rms symmetrical amperes at the drive maximum rated
voltage.
Frequency 50/60 Hz ± 5%, maximum rate of change 17%/s
Imbalance Max. ±3% of nominal phase to phase input voltage
Fundamental power factor
(cos phi
1
)
0.98 (at nominal load)
Motor connection
Voltage (U
2
) 0 to U
1
, 3-phase symmetrical, U
max
at the field weakening point
Short-circuit protection
(IEC 61800-5-1, UL 508C)
The motor output is short-circuit proof by IEC 61800-5-1 and UL 508C.
Frequency Scalar control: 0…500 Hz
Frequency resolution 0.01 Hz
Current See section Ratings on page 113.
Power limit 1.5 · P
N
Field weakening point 10…500 Hz
Switching frequency 4, 8, 12 or 16 kHz
Maximum recommended
motor cable length
R0: 30 m (100 ft), R1…R2: 50 m (165 ft)
With output chokes the motor cable length may be extended to 60 m (195 ft) for R0 and
100 m (330 ft) for R1…R2.
To comply with the European EMC Directive, use the cable lengths specified in the table
below for 4 kHz switching frequency. The lengths are given for using the drive with the
internal EMC filter or an optional external EMC filter.
4 kHz switching frequency Internal EMC filter Optional external EMC filter
Second environment
(category C3
1)
)
30 m (100 ft) 30 m (100 ft)
First environment
(category C2
1)
)
- 30 m (100 ft)
1)
See the new terms in section IEC/EN 61800-3 (2004) Definitions on page 123.
