ABB ACS150 User Manual

Control panel
55
Changed Parameters mode
In the Changed Parameters mode, you can:
• view a list of all parameters that have been changed from the macro default
values
• change these parameters
• start, stop, change direction, switch between local and remote control and set the
frequency reference.
How to view and edit changed parameters
Step Action Display
1. Go to the Main menu by pressing if you are in the Output mode,
otherwise by pressing repeatedly until you see MENU at the bottom.
2. If the panel is not in the Changed Parameters mode (“PArCh” not visible),
press key or until you see “PArCh” and then press . The
display shows the number of the first changed parameter and PAR is
flashing.
3. Use keys and to find the desired changed parameter on the
list.
4. Press and hold for about two seconds until the display shows the
value of the parameter with underneath indicating that changing of the
value is now possible.
Note: When is visible, pressing keys and
simultaneously changes the displayed value to the default value of the
parameter.
5. Use keys and to select the parameter value. When you have
changed the parameter value, starts flashing.
• To save the displayed parameter value, press .
• To cancel the new value and keep the original, press .
LOC
MENU FWD
rEF
LOC
MENU FWD
PArCh
LOC
PAR FWD
1103
LOC
PAR FWD
1003
SET
SET
LOC
PAR SET FWD
1
SET
LOC
PAR SET FWD
2
LOC
PAR FWD
1003

ABB ACS150 Specifications

General

Power Range	0.37 to 4 kW
Voltage Range	200 to 240 V, 380 to 480 V
Frequency	50/60 Hz
Control Method	Scalar control
Protection Class	IP20
Frequency Range	0 to 500 Hz
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % (non-condensing)
Ambient Temperature	-10 to +50 °C
I/O	Digital inputs, Analog inputs, Relay outputs
Overload Capacity	150% for 60 seconds
Braking Chopper	Built-in (for some models)
