ABB ACS150 User Manual

Actual signals and parameters
65
Actual signals and parameters
What this chapter contains
The chapter describes the actual signals and parameters.
Terms and abbreviations
Default parameter values with different macros
When application macro is changed (9902 APPLIC MACRO), the software updates
the parameter values to their default values. The following table includes the
parameter default values for different macros. For other parameters, the default
values are the same for all macros (see section Actual signals on page 70).
Term Definition
Actual signal Signal measured or calculated by the drive. Can be monitored by the user.
No user setting possible. Groups 01...04 contain actual signals.
Def Parameter default value
Parameter A user-adjustable operation instruction of the drive. Groups 10...99 contain
parameters.
Index Name/Selection ABB STANDARD 3-WIRE ALTERNATE MOTOR POT HAND/AUTO
1001 EXT1 COMMANDS 2 = DI1,2 4 = DI1P,2P,3 9 = DI1F,2R 2 = DI1,2 2 = DI1,2
1002 EXT2 COMMANDS 0 = NOT SEL 0 = NOT SEL 0 = NOT SEL 0 = NOT SEL 21 = DI5,4
1102 EXT1/EXT2 SEL 0 = EXT1 0 = EXT1 0 = EXT1 0 = EXT1 3 = DI3
1103 REF1 SELECT 1 = AI1 1 = AI1 1 = AI1 12 = DI3U,4D(NC) 1 = AI1
1106 REF2 SELECT 2 = POT 2 = POT 2 = POT 1 = AI1 2 = POT
1201 CONST SPEED SEL 9 = DI3,4 10 = DI4,5 9 = DI3,4 5 = DI5 0 = NOT SEL
1301 MINIMUM AI1 0% 0% 0% 0% 20%
2201 ACC/DEC 1/2 SEL 5 = DI5 0 = NOT SEL 5 = DI5 0 = NOT SEL 0 = NOT SEL
9902 APPLIC MACRO 1 = ABB STANDARD 2 = 3-WIRE 3 = ALTERNATE 4 = MOTOR POT 5 = HAND/AUTO

ABB ACS150 Specifications

General

Power Range	0.37 to 4 kW
Voltage Range	200 to 240 V, 380 to 480 V
Frequency	50/60 Hz
Control Method	Scalar control
Protection Class	IP20
Frequency Range	0 to 500 Hz
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % (non-condensing)
Ambient Temperature	-10 to +50 °C
I/O	Digital inputs, Analog inputs, Relay outputs
Overload Capacity	150% for 60 seconds
Braking Chopper	Built-in (for some models)
