ABB ACS580-01 drives User Manual

19
R0-
R4
R5
R6-
R9
EN
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZH
Ratings and fuses
I
II
Type
ACS580
Input
rating
Output ratings Maximum
losses
Frame
size
Nominal use Heavy duty use
-01-
I
1N
I
N
P
N
I
Ld
P
Ld
I
Hd
P
Hd
A A kW A kW A kW W
3-phase U
N
= 400 V (380…415 V)
02A6-4 2.6 2.6 0.75 2.5 0.75 1.8 0.55 45 R0
03A3-4 3.3 3.3 1.1 3.1 1.1 2.6 0.75 55 R0
04A0-4 4.0 4.0 1.5 3.8 1.5 3.3 1.1 66 R0
05A6-4 5.6 5.6 2.2 5.3 2.2 4.0 1.5 84 R0
07A2-4 7.2 7.2 3.0 6.8 3.0 5.6 2.2 106 R1
09A4-4 9.4 9.4 4.0 8.9 4.0 7.2 3.0 133 R1
12A6-4 12.6 12.6 5.5 12.0 5.5 9.4 4.0 174 R1
017A-4 17 17 7.5 16.2 7.5 12.6 5.5 228 R2
025A-4 25 25 11.0 23.8 11.0 17.0 7.5 322 R2
032A-4 32 32 15.0 30.4 15.0 24.6 11 430 R3
038A-4 38 38 18.5 36.1 18.5 31.6 15 525 R3
045A-4 45 45 22.0 42.8 22.0 37.7 18.5 619 R3
062A-4 62 62 30 58 30 45 22 835 R4
073A-4 73 73 37 68 37 61 30 1024 R4
3AXD00000586715.xls H
Type
ACS580
Input
rating
Output ratings Maximum
losses
Frame
size
Nominal use Heavy duty use
-01-
I
1N
I
Ld
P
Ld
I
Hd
P
Hd
A A hp A hp W
3-phase U
N
= 480 V (440…480 V)
02A6-4 2.1 2.1 1.0 1.6 0.75 45 R0
03A3-4 3.0 3.0 1.5 2.1 1.0 55 R0
04A0-4 3.4 3.4 2.0 3.0 1.5 66 R0
05A6-4 4.8 4.8 3.0 3.4 2.0 84 R0
07A2-4 6.0 6.0 3.0 4.0 3.0 106 R1
09A4-4 7.6 7.6 5.0 4.8 3.0 133 R1
12A6-4 11.0 11.0 7.5 7.6 5.0 174 R1
017A-4 14 14.0 10.0 11.0 7.5 228 R2
025A-4 21 21.0 15.0 14.0 10.0 322 R2
032A-4 27 27.0 20.0 21.0 15.0 430 R3
038A-4 34 34.0 25.0 27.0 20.0 525 R3
045A-4 40 40.0 30.0 34.0 25.0 619 R3
062A-4 52 52 40 40 30 835 R4
073A-4 65 65 50 52 40 1024 R4
3AXD00000586715.xls H
3AUA0000076332 Rev E

ABB ACS580-01 drives Specifications

General

Control method	Scalar control, Vector control
Frequency	0 to 500 Hz
Communication protocols	Modbus RTU, Ethernet/IP, Profibus DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage
Enclosure rating	IP21, IP55
Ambient temperature	-15 to +50 °C
Storage temperature	-40 to +70 °C
Relative humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m (without derating), up to 4000 m (with derating)
EMC Filter	Built-in
Voltage range	208 to 480 V
Braking Chopper	Built-in up to 22 kW
