ABB ACS580-01 drives User Manual

20
R0-
R4
R5
R6-
R9
EN
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZH
III
IV
Type
ACS580
-01-
gG
I
N
I
2
t Voltage rating ABB type
Type
IEC 60269
A A
2
s V
3-phase U
N
= 400/480 V (380…415 V, 440…480 V)
02A6-4 4 55 500 OFAF000H4 000
03A3-4 6 110 500 OFAF000H6 000
04A0-4 6 110 500 OFAF000H6 000
05A6-4 10 360 500 OFAF000H10 000
07A2-4 10 360 500 OFAF000H10 000
09A4-4 16 740 500 OFAF000H16 000
12A6-4 16 740 500 OFAF000H16 000
017A-4 25 2500 500 OFAF000H25 000
025A-4 32 4000 500 OFAF000H32 000
032A-4 40 7700 500 OFAF000H40 000
038A-4 50 16000 500 OFAF000H50 000
045A-4 63 20100 500 OFAF000H63 000
062A-4 80 37500 500 OFAF000H80 000
073A-4 100 65000 500 OFAF000H100 000
3AXD00000586715.xls H
Type
ACS580
-01-
uR or aR
I
N
I
2
t Voltage rating Bussmann type
Type
IEC 60269
A A
2
s V
3-phase U
N
= 400/480 V (380…415 V, 440…480 V)
02A6-4 25 130 690 170M1561 000
03A3-4 25 130 690 170M1561 000
04A0-4 25 130 690 170M1561 000
05A6-4 25 130 690 170M1561 000
07A2-4 25 130 690 170M1561 000
09A4-4 25 130 690 170M1561 000
12A6-4 25 130 690 170M1561 000
017A-4 40 460 690 170M1563 000
025A-4 40 460 690 170M1563 000
032A-4 63 1450 690 170M1565 000
038A-4 63 1450 690 170M1565 000
045A-4 80 2550 690 170M1566 000
062A-4 100 4650 690 170M1567 000
073A-4 125 8500 690 170M1568 000
3AXD00000586715.xls H

ABB ACS580-01 drives Specifications

General

Control method	Scalar control, Vector control
Frequency	0 to 500 Hz
Communication protocols	Modbus RTU, Ethernet/IP, Profibus DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage
Enclosure rating	IP21, IP55
Ambient temperature	-15 to +50 °C
Storage temperature	-40 to +70 °C
Relative humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m (without derating), up to 4000 m (with derating)
EMC Filter	Built-in
Voltage range	208 to 480 V
Braking Chopper	Built-in up to 22 kW
