ABB ACS580-01 drives User Manual

21
R0-
R4
R5
R6-
R9
EN
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZH
V
Type
ACS580
-01-
UL
I
N
Voltage rating Bussmann type
UL class
A V
3-phase U
N
= 460 V (440…480 V)
02A6-4 3 600 JJS-3 T
03A3-4 6 600 JJS-6 T
04A0-4 6 600 JJS-6 T
05A6-4 10 600 JJS-10 T
07A2-4 10 600 JJS-10 T
09A4-4 15 600 JJS-15 T
12A6-4 20 600 JJS-20 T
017A-4 25 600 JJS-25 T
025A-4 35 600 JJS-35 T
032A-4 40 600 JJS-40 T
038A-4 50 600 JJS-50 T
045A-4 60 600 JJS-60 T
062A-4 80 600 JJS-80 T
073A-4 90 600 JJS-90 T
3AXD00000586715.xls H

ABB ACS580-01 drives Specifications

General

Control method	Scalar control, Vector control
Frequency	0 to 500 Hz
Communication protocols	Modbus RTU, Ethernet/IP, Profibus DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage
Enclosure rating	IP21, IP55
Ambient temperature	-15 to +50 °C
Storage temperature	-40 to +70 °C
Relative humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m (without derating), up to 4000 m (with derating)
EMC Filter	Built-in
Voltage range	208 to 480 V
Braking Chopper	Built-in up to 22 kW
