ABB ACS580-01 drives User Manual

315
R5 Figures A B
c
a
d
e
b
5
2
R5 IP21 R5 IP55
mm in mm in
a 612 24.09 612 24.09
b 581 22.87 581 22.87
c 160 6.30 160 6.30
d > 200 7.9 200 7.9
e > 200 7.9 200 7.9
R5 IP21 R5 IP55
kg lb kg lb
28.3 62.4 28.6 63.1
1
4
× 2
× 2
× 6
4a
4b
4c
IP21 IP21
3
× 2
× 2
6
8
9
10
M5 × 3
7
7a
7b
8a
8b
9a
9b
9b
IP21
IP21
7b
IP21
1
3a
ONLY IT SYSTEMS
EN: See page 175. DA: Se side 185. DE: Siehe Seite 195. ES: Véase la página 205.
FI: Katso sivu 215. FR: Cf. page 225. IT: Vedere pag. 235. NL: Zie pagina 245.
PL: Patrz str. 255. PT: Vejaapágina265. RU: См. стр. 275. SV: Se sidan 285.
TR: Bkz. sayfa 295. ZH: 请参阅第 305.
4
5
6
3b
3c
4a
4b
× 8
5a
5b
5c
IP21
IP55
3
IP21
1000
V DC,
>
100
Mohm
U1-V1, U1-W1, V1-W1
U1-PE, V1-PE, W1-PE
ohm
M
3~
U1
V1
W1
PE
L3
L2
L1
EMC
VAR
ACS580
ACS580
PE
L3
L2
L1
× 2
× 2
× 2

ABB ACS580-01 drives Specifications

General

Control method	Scalar control, Vector control
Frequency	0 to 500 Hz
Communication protocols	Modbus RTU, Ethernet/IP, Profibus DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage
Enclosure rating	IP21, IP55
Ambient temperature	-15 to +50 °C
Storage temperature	-40 to +70 °C
Relative humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m (without derating), up to 4000 m (with derating)
EMC Filter	Built-in
Voltage range	208 to 480 V
Braking Chopper	Built-in up to 22 kW
