ABB ACS580-01 drives User Manual

316
C D E
1 2
L1 L2 L3
L1 L2 L3PE
ACS580-01 R5
PE
2a
2b
2a
T1/U T2/V T3/W
U1
V1
W1
3 ~ M
PE
PE
4b
4a
PE
Frame size T1/U, T2/V, T3/W PE,
N·m lbf·ft M N·m lbf·ft N·m lbf·ft
R5 5.6 4.1 M5 4.5 3.3 4.5 3.3
3
5
6
4a 4b
6c
6a
6b
PE
8
Frame size L1, L2, L3, PE,
N·m lbf·ft M N·m lbf·ft N·m lbf·ft
R5 5.6 4.1 M5 4.5 3.3 4.5 3.3
7b7a
PE
PE
8c
8b
8a
9
10
9a
9b
10a
10b
3AUA0000076332 Rev E

ABB ACS580-01 drives Specifications

General

Control method	Scalar control, Vector control
Frequency	0 to 500 Hz
Communication protocols	Modbus RTU, Ethernet/IP, Profibus DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage
Enclosure rating	IP21, IP55
Ambient temperature	-15 to +50 °C
Storage temperature	-40 to +70 °C
Relative humidity	5 to 95% (non-condensing)
Altitude	Up to 1000 m (without derating), up to 4000 m (with derating)
EMC Filter	Built-in
Voltage range	208 to 480 V
Braking Chopper	Built-in up to 22 kW
