Mechanical installation 11
Mechanical installation
Safety
All installation work must be carried out by qualified personnel according to the site
and equipment requirements and in compliance with the local regulations.
Examining the installation site
The installation site is sufficiently ventilated or cooled to transfer away the drive
losses. The maximum heat losses and cooling air flow are listed in
ACS580MV
Engineering Guideline (2UBB013672 [English]).
The ambient conditions of the drive shall not be higher than 40°C during operation
of the drive. In case the temperature out of the scope, contact ABB to get support.
ACS580MV can be installed using one of the four following cooling solutions:
• Air conditioner solution (recommended)
• Air duct solution
• Fresh air circulation solution
• Air-to-water heat exchanger solution
