12 Mechanical installation
Attention:
• The wall behind the unit is of non-flammable material.
• The floor that the unit is installed on is of non-flammable material.
• The maximum allowed floor flatness deviation from the surface level is 5mm in
every 5 meters.
• Minimal distance between the drive and the wall:
• Front side: 1600 mm
• Rear side: 100 mm
• Top side: 400 mm
• Left side: 100 mm
• Right side: 100 mm
Installation of EC fan units
AC fans are already mounted when delivered.
EC fans need to be installed with fan box on site.
For information on the number of fan unit for installation, see
ACS580MV Outline
Drawing.
