Lifting and transportation 31
Lifting and transportation
Safety
• The drive must only be handled by personnel who are skilled and experienced in
unpacking and transporting heavy equipment.
• All work must be carried out by qualified personnel according to the site and
equipment.
• Choose the load capacity and find the center of gravity from ACS580MV outline
drawing.
Using a crane or forklift
• Ensure that the slope angle (position 1 in figure below) is in accordance with the
weight of the cabinet.
• Only transport the cabinet with the long side facing the driving direction.
• Use forks with sufficient length to ensure stable transportation and to prevent
tipping.
• The fork must be at least as long as the cabinet.
• Insert the fork fully into the cabinet’s forklift pockets.
