20 Electrical installation
Drawing of system cabling
1
2
3
4
5
6
7
8
4
4
5
1Input transformer (TRU)
2Drive
3Motor
4 Earth electrode
5 Ground cable
6 Cable insulation layer
7 Cable shield
8 Equipotential bonding conductor
