110 Technical data
ACS800-
01 size
Input
current
Fuse
A
A
2
s
V Manufacturer Type IEC size
Three-phase supply voltage 208 V, 220 V, 230 V or 240 V
-0001-2 4.4 10 483 500 ABB Control OFAF000H10 000
-0002-2 5.2 10 483 500 ABB Control OFAF000H10 000
-0003-2 6.7 10 483 500 ABB Control OFAF000H10 000
-0004-2 9.3 16 993 500 ABB Control OFAF000H16 000
-0005-2 12 16 993 500 ABB Control OFAF000H16 000
-0006-2 16 20 1620 500 ABB Control OFAF000H20 000
-0009-2 23 25 3100 500 ABB Control OFAF000H25 000
-0011-2 31 40 9140 500 ABB Control OFAF000H40 000
-0016-2 40 50 15400 500 ABB Control OFAF000H50 000
-0020-2 51 63 21300 500 ABB Control OFAF000H63 000
Three-phase supply voltage 380 V, 400 V or 415 V
-0003-3 4.7 10 483 500 ABB Control OFAF000H10 000
-0004-3 6.0 10 483 500 ABB Control OFAF000H10 000
-0005-3 7.9 10 483 500 ABB Control OFAF000H10 000
-0006-3 10 16 993 500 ABB Control OFAF000H16 000
-0009-3 13 16 993 500 ABB Control OFAF000H16 000
-0011-3 17 20 1620 500 ABB Control OFAF000H20 000
-0016-3 23 25 3100 500 ABB Control OFAF000H25 000
-0020-3 32 40 9140 500 ABB Control OFAF000H40 000
-0025-3 42 50 15400 500 ABB Control OFAF000H50 000
-0030-3 53 63 21300 500 ABB Control OFAF000H63 000
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
-0004-5 4.7 10 483 500 ABB Control OFAF000H10 000
-0005-5 5.9 10 483 500 ABB Control OFAF000H10 000
-0006-5 7.7 10 483 500 ABB Control OFAF000H10 000
-0009-5 10.0 16 993 500 ABB Control OFAF000H16 000
-0011-5 12.5 16 993 500 ABB Control OFAF000H16 000
-0016-5 17 20 1620 500 ABB Control OFAF000H20 000
-0020-5 23 25 3100 500 ABB Control OFAF000H25 000
-0025-5 31 40 9140 500 ABB Control OFAF000H40 000
-0030-5 41 50 15400 500 ABB Control OFAF000H50 000
-0040-5 47 63 21300 500 ABB Control OFAF000H63 000
Three-phase supply voltage 525 V, 550 V, 575 V, 600 V, 660 V or 690 V
-0011-7 12 16 1100 690 ABB Control OFAA000GG16 000
-0016-7 15 20 2430 690 ABB Control OFAA000GG20 000
-0020-7 21 25 4000 690 ABB Control OFAA000GG25 000
-0025-7 24 32 7000 690 ABB Control OFAA000GG32 000
-0030-7 33 35 11400 690 ABB Control OFAA000GG35 000
-0040-7 35 50 22800 690 ABB Control OFAA000GG50 000
