Technical data 125
Energy efficiency data (ecodesign)
Energy efficiency data according to IEC 61800-9-2 is available from the
ecodesign tool (https://ecodesign.drivesmotors.abb.com).
Cooling
Method Internal fan, flow direction from bottom to top.
Free space around the
unit
See
Mechanical installation
(page 27).
Degree of protection
IP21 (UL type 1) and IP55 (UL type 12). Without the connection box and front
cover, the unit must be protected against contact according to IP2x [see
Cabinet installation (IP21, UL type 1)
on page 68].
AGPS-11C (option +Q950)
Nominal input voltage 115...230 V AC ±10%
Nominal input current 0.1 A (230 V) / 0.2 A (115 V)
Nominal frequency 50/60 Hz
Max. external fuse 16 A
X1 terminal sizes
3 x 2.5 mm
2
Output voltage 15 V DC ±0.5 V
Nominal output current 0.4 A
X2 terminal block type JST B4P-VH
Degree of protection IP20
Ambient temperature 0...50 °C (32...122 °F)
Relative humidity Max. 90%, no condensation allowed
Dimensions (with
enclosure)
167 x 128 x 52 mm (height x weight x depth)
Weight (with enclosure) 0.75 kg (1.65 lb)
Approvals C-UL, US listed
ASTO-11C (option +Q967)
Supply voltage range +24 V DC +/- 10%
Current consumption 40 mA (20 mA per channel)
Supply cable A single-shielded twisted pair
Maximum cable length 300 m
Conductor min. cross
section
0.5 mm
2
, 20 AWG
X1 terminal sizes
4 x 2.5 mm
2
Nominal output current 0.4 A
X2 terminal block type JST B4P-VH
Degree of protection IP20
Ambient temperature 0...50 °C (32...122 °F)
Relative humidity Max. 90%, no condensation allowed
Altitude in operation 0…2000 m (6562 ft)
Dimensions (with
enclosure)
167 x 128 x 52 mm (height x weight x depth)
Weight (with enclosure) 0.75 kg (1.65 lb)
