ABB ACS800-U1 User Manual

126 Technical data
Ambient conditions
Environmental limits for the drive are given below. The drive is to be used in
a heated, indoor, controlled environment.
Operation
installed for stationary
use
Storage
in the protective
package
Transportation
in the protective
package
Installation site altitude 0 to 4000 m (13123 ft)
above sea level [above
1000 m (3281 ft), see
Derating on page 109].
Drives with option
+Q967:
0 to 2000 (6562 ft)
--
Air temperature -15 to +50 °C (5 to 122
°F).
No frost allowed.
See
Derating (page 109) .
-40 to +70 °C
(-40 to +158 °F)
-40 to +70 °C
(-40 to +158 °F)
Relative humidity 5 to 95% Max. 95% Max. 95%
No condensation allowed. Maximum allowed relative humidity is 60% in the
presence of corrosive gases.
Contamination levels
(IEC 60721-3-3,
IEC 60721-3-2, IEC 60721-
3-1)
No conductive dust allowed.
Boards without
coating:
Chemical gases: Class
3C1
Solid particles: Class 3S2
Boards with coating:
Chemical gases: Class
3C2
Solid particles: Class 3S2
Boards without
coating:
Chemical gases: Class
1C2
Solid particles: Class 1S3
Boards with coating:
Chemical gases: Class
1C2
Solid particles: Class 1S3
Boards without
coating:
Chemical gases: Class
2C2
Solid particles: Class 2S2
Boards with coating:
Chemical gases: Class
2C2
Solid particles: Class 2S2
Atmospheric pressure 70 to 106 kPa
0.7 to 1.05 atmospheres
70 to 106 kPa
0.7 to 1.05 atmospheres
60 to 106 kPa
0.6 to 1.05 atmospheres
Vibration (IEC 60068-2) Max. 1 mm (0.04 in.)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz)
sinusoidal
Max. 1 mm (0.04 in.)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz)
sinusoidal
Max. 3.5 mm (0.14 in.)
(2 to 9 Hz),
max. 15 m/s
2
(49 ft/s
2
)
(9 to 200 Hz) sinusoidal
Shock (IEC 60068-2-27) Not allowed
Max. 100 m/s
2
(330
ft./s
2
), 11 ms
Max. 100 m/s
2
(330
ft./s
2
), 11 ms
Free fall Not allowed 250 mm (10 in.) for
weight under 100 kg
(220 lb)
100 mm (4 in.) for
weight over 100 kg (220
lb)
250 mm (10 in.) for
weight under 100 kg
(220 lb)
100 mm (4 in.) for
weight over 100 kg (220
lb)
